SAIA   PCD3.R60X 网络安全控制器 这有助于确保系统和流程的不间断运行

PCD3.R60X   网络安全控制器

功能强大的PCD3。M6893是一款网络安全PLC, 可编程符合IEC 61131-3。根据IEC61131-3，用于结构化文本(ST)的语言具有强大的语法并支持面向对象的方法。新的网络安全级别(ANSI ISA62443 - SL3 / SL4)可用于关键任务和物联网/云应用。这种模块化PLC提供集成的USB,以太网，RS-485和CAN总线接口。 它与SBC PCD3系列的模块化和强大的I / 0系统用PCD3。M6893控制器， 可实现冗余自动化解决方案。这有助于确保系统和流程的不间断运行。
大外设连接数
●板载以太网和usb接口
●一个串行接口RS-485板载
●1个串行接口RS-485可插在插槽A
●多达1023个中央输入/输出与扩展模块支架PCD3。Cx00(多64个模块与大。各16个接触点)。第 一个模块持有人必须始终PCD3。C200
●额外的远程输入/输出通过Modbus IP与PCD控制器和/O模块
式PCD3 /O模块
超过40个不同功能的I/O模块，请参阅订单详细信息
●通过led指示数字信号的状态
●通过系统配置软件配置进程映像

Powerful PCD3. M6893 is a network security PLC that can be programmed in accordance with IEC 61131-3. According to IEC61131-3, high-level languages for structured text (ST) have powerful syntax and support object-oriented methods. The new network security level (ANSI ISA62443- SL3/SL4) can be used for critical tasks and IoT/cloud applications. This modular PLC provides integrated USB, Ethernet, RS-485, and CAN bus interfaces. It is compatible with the modular and powerful I/O system of the SBC PCD3 series using PCD3. M6893 controller, capable of achieving redundant automation solutions. This helps to ensure uninterrupted operation of systems and processes.
Large number of peripheral connections
● On board Ethernet and USB interfaces
One serial interface RS-485 onboard
1 serial interface RS-485 can be plugged into slot A
Up to 1023 central input/output and expansion module brackets PCD3. Cx00 (64 more modules and 16 contact points each). The first module holder must always be PCD3. C200
● Additional remote input/output via Modbus IP with PCD controller and/O module
Type PCD3/O module
More than 40 I/O modules with different functions, please refer to the order details
● Indication of digital signal status through LED
● Configure process images through system configuration software
